Описание
| AC Inputnbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; | 100-240Vac~ 13-6A 50-60Hz (Not for China)/200-240Vac~ 6A 50-60Hz (Only for China) |
| DC Output | +3.3V/+5V/+12V/-12V/+5Vsb |
| Max Output Current | 20A/20A/83.33A/0.3A/3A |
| Max Combined Power | 120W/1000W/18.6W |
| Total Power | 1000W |
SPECIFICATIONS
| Modelnbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; nbsp; | HPT3-1000M,Gen5 |
| Rated Output Power | 1000W |
| Form Factor | ATX |
| 80 PLUS Certification | Platinum |
| Input Voltage | 100-240V |
| Input Current | 13-6A |
| Input Frequency | 50-60Hz |
| PFC | Active PFC |
| Efficiency | 92% |
| Fan Type | FDB fan, 120mm |
| Dimensions(L x W x H) | 130×150×86 mm |
| nbsp; | nbsp; |
| Protection | OCP,OVP OPP, SCP, OTP |
